Custom Super Clear Vision Led Traffic Signs For Road Construction

    Buy cheap Custom Super Clear Vision Led Traffic Signs For Road Construction from wholesalers

    Buy cheap Custom Super Clear Vision Led Traffic Signs For Road Construction from wholesalers
    • Buy cheap Custom Super Clear Vision Led Traffic Signs For Road Construction from wholesalers

    Custom Super Clear Vision Led Traffic Signs For Road Construction

    Ask Lasest Price
    Brand Name : YAHAM
    Model Number : VMS
    Certification : CE/ FCC
    Price : Negotiation
    Payment Terms : T/T or FOB Shenzhen
    Supply Ability : 3,000pcs per month
    Delivery Time : 40 working days after received your payment
    • Product Details
    • Company Profile

    Custom Super Clear Vision Led Traffic Signs For Road Construction


    Custom Super Clear Vision Led Traffic Signs For Road Construction


    Variable Traffic Sign(VTS) guide a safer way for the driver to go ahead. The lane control sign and speed limit sign gives clear information to lead you enter the right lane and with the right driving speed. With Yaham unique system, it is easy to vary the traffic message.


    Specifications:


    ProductYHT-OT16
    LED Type3 in 1 SMD type
    Pixel Pitch16mm
    Pixel Density3,906 pixel/ m2
    Pixel Configuration1R1G1B
    Module Dimension (H x W)128mm*256mm
    Module Resolution (H x W)8*16mm
    Cabinet Dimension (H x W x D)1024mm*1024mm
    Cabinet Resolution (H x W)64*64
    Screen Weight65KG/sqm AL; 85KG/sqm Steel
    Viewing Angle30°/ 25°
    Best Viewing Distance16m+
    MaintenanceRear service
    Protection LevelIP65
    Brightness(Peak White at 6,500k)

    Red: >3100nits, Green>3720nits, Blue>1240nits,

    Amber>7440nits, White:>12400nits

    ColourFull color
    Contrast RatioWhite 16.7 Yellow10,Green5,Red4.2,Blue1.7
    Power Supply88 ~ 264VAC ,124 ~ 370VDC
    Operation Temp.-20℃-+60℃
    Storage Temp.-40℃-+80℃
    Operation Humidity.5%-95%RH
    Display CapacityText / Image
    Driving Method1 scan
    PowerConsumption200 W/sqm(Max.)


    Description:


    IP65 for pressure washing and harsh weather
    Durable power supply(12V/24V) unit
    Protected from shock and movable by truck
    Wireless and remote control

    Applications:


    used for Tunnel/ Toll collection station
